Image Sensor
1/2.7" Progressive Scan CMOS
Max. Resolution
5MP 2592(H)x1944(V)
Min. Illumination
Color: 0.003 Lux @ (F1.6, AGC ON), B/W:0 Lux with IR
Focal Length
Max. F1.6, 4.3mm-142mm, 33X Optical Zoom
Movement Range(Pan)
360°
Movement Range(Tilt)
-10° to 90° (auto flip)
WDR
120dB
Shutter Time
1/5 - 1/20000
Day& Night
Auto Switch
Video Compression
H.264&H.265
Water Proof
IP67
Pan Range
360°endless
Power Supply
DC 12V/PoE+, max. 25.6W
Working Temperature
-30〜+60°C, < 90%(outdoor）

Imaging Device: 1/2.7"
Effective Pixels: 2MP 1920(H)×1080(V)
Min. Illumination: Color 0.0005 Lux @（F1.0, AGC ON: B/W 0 lux @ IR ON
Focal Length (Zoom Ratio): 3.6mm
Angular Field of View: Horizontal:88.88° , Vertica l48.25°, Diagona l105.59
Min. Object Distance: 1m
Lens Type: Fixed(M12)
IR LED: 2
WarmLight: 2
IR Viewable Length: Up to 30m
WarmLight Viewable Length:Up to 25m
WideDynamic Range: DWDR
Image Setting: Full Color Mode/Day&Night Mode/Schedule
White Balance: Auto/Manual
Electronic Shutter Speed: 1/5 ~ 1/20000s
On-Board Storage: Micro SD slot, up to 256GB
Alarm: NA
Audio: Built-in microphone
Hardware Reset: Yes
Smart Feature: NA
Ethernet: RJ45(10/100BASE-T)
Video Compression Format:H.265/H.264
Max.Resolution: 2MP(1920x1080)@30fps
Video Quality Ajustment: 128Kbps ~ 4Mbps
Protocol:TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
Application Programming Interface: ONVIF
Operating Conditions: -30〜+55°C / less than ≤ 95% RH
Ingress Protection:IPP66
Input Voltage / Current:D12V/PoE(IEEE802.3af)
Material:Metal

Imaging Device
1/2.7"
Effective Pixels
2MP 1920(H)×1080(V)
Min. Illumination
Color 0.001lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON
Focal Length
3.6mm
Lens Type
Fixed(M12)
WarmLight
4
IR LED
4
IR Viewable Length
Up to 35m
WarmLight Viewable Length
Up to 30m
Wide Dynamic Range
DWDR
Image Setting
Full Color Mode/Day&Night Mode/Schedule
Max. Resolution
2MP(1920x1080)@30fps
Operating Conditions
-30～+60°C/less than ≤ 95% RH
Ingress Protection
IP67
Input Voltage / Current
D12V/POE(IEEE802.3af)

Imaging Device
1/2.7"
Effective Pixels
2MP 1920(H)×1080(V)
Min. Illumination
Color 0.001lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON
Focal Length
3.6mm
Lens Type
Fixed(M12)
WarmLight
2
IR LED
2
IR Viewable Length
Up to 30m
WarmLight Viewable Length
Up to 25m
Wide Dynamic Range
DWDR
Image Setting
Full Color Mode/Day&Night Mode/Schedule
Max. Resolution
2MP(1920x1080)@30fps
Operating Conditions
-35～+60°C/less than ≤ 95% RH
Ingress Protection
IP67
Input Voltage / Current
D12V/POE(IEEE802.3af)

Model: RS-CH251H2V-EDF-WA0550PW
Resolution: 5MP 2592(H)×1944(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination Color: 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
ShutterI 1/5 ~ 1/20000s
Lens: 5 ~ 50 (Motorized) mm H.FOV: 45 ~ 7° F No. F No. 2.0±5%
Day & Night: IR cut filter with auto switch
WDR: 120 dB
Video Compression: H.265/H.264
Video bit rate: 256Kbps ~ 12Mbps
Triple Stream: yes
Resolution:
Mainstream（default 30fps）
5MP (3072x1728)(2592x1944),
4MP(2592x1520), 3MP(2304x1296)
1080P(1920x1080), 720P(1280x720),
Substeam（default 30fps )
720P(1280x720),VGA(640x480),
QVGA(320x240)
Mobilestream（default 10fps）
VGA(640x480), QVGA（320x240）"
Image Settings: Rotate Mode, Saturation, Brightness, Contrast, Sharpness, Hue adjustable
BLC: Support
ROI: Support
Video Analytics: Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection,Face Detection(DEEP LEARNING),Cross Counting.
Protocols: "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,"
System Compatibility: ONVIF( Ver 2.6, Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led: 8pcs(Array)
IR Range: Up to 80m
SD storage: yes（Micro SD/SDHC/SDXC slot, up to 128 GB）
Alarm Trigger: 1 input / 1 output
Audio: 1 input / 1 output (RCA)
Video Output: yes
Reset Button: yes
PoE: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: ≤ 9W
Dimension: Ø108 X 301mm
Weight appr: 1427g
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Model: RS-CH251H2T-WA2812PW
Resolution: 5MP 2592(H)×1944(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination Color: 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.7 ~ 13.5mm (Varifocal) H.FOV: 99 ~ 30° F No. F No. W:1.6--T:2.9±5%
Day & Night: IR cut filter with auto switch（Day/Night/Auto/Schedule）（Day/Night/Auto/Schedule）（Day/Night/Auto/Schedule）
Digital noise reduction: 3D DNR
WDR: 120 dB
Video Compression: H.265/H.264
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: yes
Resolution:
Mainstream（1~30fps default 30fps）
5MP (2592x1944),4MP(2592x1520),
3MP(2304x1296)(2048x1535)
1080P(1920x1080), 720P(1280x720),
Substeam（1~30fps default 10fps )
720P(1280x720),
VGA(640x480),QVGA(320x240)
Mobilestream（1~30fps default 10fps）
VGA(640x480), QVGA（320x240）"
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Video Analytics: Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection,Face Detection(DEEP LEARNING),Cross Counting.
Protocols: "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,"
System Compatibility: ONVIF( Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led: 40 pcs(SMD)
IR Range: Up to 50 m
SD storage: yes（Micro SD/SDHC/SDXC slot, up to 128 GB）
Alarm Trigger: 1 input / 1 output
Audio: 1 input / 1 output (RCA)
Video: Output: yes
Reset Button: yes
PoE: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: ≤ 9W
Dimension: Ø88 X 242mm
Weight appr.: 881g
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Resolution: 2MP 1920(H)×1080(V)
Image Sensor: 1/2.7" Progressive CMOS
Min. Illumination: Color 0.03lux @ F1.2(AGC ON)
Lens: 3.6 mm F 2.0±5%
Day & Night: IR cut filter with auto switch
WDR: Digital WDR
Video bit rate: 128Kbps ~ 8Mbps
Dual Stream: Main, Moblie
Frame Rate: Mainstream(1-25fps optional)
1080P(1920x1080), 960P(1280x960), 720P(1280x720)
Mobilestream: VGA(640x480), QVGA（320x240）
Protocols: TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
Image Settings: Rotate mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC: Support
ROI: no
Privacy Mask: Support
Video Analytics: no
System Compatibility: ONVIF( Profile S, Profile G)
Led & IR Range :18pcs&30m
Water Proof: IP 66
PIR Angle: no
PIR Distance: no
SD storage: Support (optional)
Alarm Trigger: no
Audio: Support (optional)
Video Output: no
Power Supply: DC 12V/POE
Consumption: ≤4.5W
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Effective Pixel 2MP 1920(H) x 1080(V)
Video Compression H.265/H.264
Scan System Progressive Scan
Synchronization Internal
Minimum Illumination 0.05lux@F1.2(AGC ON),0Lux with IR
Resolution Mainstream:(1-20fps optional) 1080P 1920x1080,960P(1280x960P), 720P(1280x720P) Substream:VGA(640x480),QVGA(320x240)
Aspect Ratio 16:9
Storage Support Micro SD card
White Balance AUTO/INDOOR/MANUAL
AES Speed 1/5s – 1/20000s/AUTO AGC Off/Low/Mid/High Optional
Noise Reduction 3D
BLC Yes
DWDR Yes
WDR Yes
Video Output RJ45
Audio Two-Way Audio
Speaker YES
Lens/ Lens Mount 3.6mm/F2.0 fixed lens
Viewing Angle D: 104° H: 87° V: 47°
Power Source DC12V±10%
Power Consumption 4.2 W
Operating Tem Range -20°C ~ 40°C
Operating Humid Range Less than 95% RH (no condensation)
Environment Rating IP66
Storage Temperature -30°C~ 60°C
Operating Temperature -30°C ~ 55°C
Camera Housing Material Metal
RoHS Compliance Yes
Smart IR Yes
IR Night Vision Range 20m
Built-in IR LED/ICR Yes, 2 Array IR
IR LED Type 850nm
IR Angle 100°
PIR Angle Up to 115°
PIR Distance Up to 7M
Flood Light 2 PCS Up to 10M

Resolution: 5MP 2592(H)×1944(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination: Color 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.7 ~ 13.5mm (Varifocal) H.FOV: 99 ~ 30°
F No. F No. W:1.6--T:2.9±5%
Day & Night: IR cut filter with auto switch
(Day/Night/Auto/Schedule)
Digital noise reduction: 3D DNR
WDR: 120 dB
Video Compression: H.265/H.264
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: yes
Resolution;
Mainstream: (1~30fps default 30fps）
5MP (2592x1944),4MP(2592x1520),
3MP(2304x1296)(2048x1535)
1080P(1920x1080), 720P(1280x720),
Substeam: (1~30fps default 10fps )
720P(1280x720),
VGA(640x480),QVGA(320x240)
Mobilestream: (1~30fps default 10fps）
VGA(640x480), QVGA（320x240)
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Video Analytics: Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection,Face Detection(DEEP LEARNING),Cross Counting.
Protocols: "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,"
System Compatibility: ONVIF( Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led: 30pcs(SMD)
IR Range: Up to 40m
SD storage: yes（Micro SD/SDHC/SDXC slot, up to 128 GB）
Alarm Trigger: 1 input / 1 output
Audio 1 input / 1 output (RCA)
Video Output: yes
Reset Button: yes
PoE: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: ≤ 9W
Dimension: Ø84 X 240mm
Weight appr.: 805g
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Resolution: 5MP 2592(H)×1944(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination: Color 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.7 ~ 13.5mm (Varifocal) H.FOV: 99 ~ 30°
F No.: F No. W:1.6--T:2.9±5%
Day & Night: IR cut filter with auto switch
(Day/Night/Auto/Schedule)
Digital noise reduction: 3D DNR
WDR: 120 dB
Video Compression: H.265/H.264
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: yes
Resolution;
Mainstream: (1~30fps default 30fps)
5MP (2592x1944),4MP(2592x1520),
3MP(2304x1296)(2048x1535)
1080P(1920x1080), 720P(1280x720),
Substeam: (1~30fps default 10fps )
720P(1280x720),
VGA(640x480),QVGA(320x240)
Mobilestream: (1~30fps default 10fps）
VGA(640x480), QVGA（320x240）"
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Video Analytics: Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection,Face Detection(DEEP LEARNING),Cross Counting.
Protocols: "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,"
System Compatibility: ONVIF( Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led: 40 pcs(SMD)
IR Range: Up to 50 m
SD storage yes（Micro SD/SDHC/SDXC slot, up to 128 GB）
Alarm Trigger: 1 input / 1 output
Audio: 1 input / 1 output (RCA)
Video Output: yes
Reset Button: yes
PoE: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: ≤ 9W
Dimension: Ø88 X 242mm
Weight appr.: 881g
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Compression: H.264/H.265
Image Sensor: 1/2.7" 2Megapixel progressive CMOS
Effective Pixels: 1920(H) x 1080(V)
Scanning System: Progressive
Minimum Illumination: 0.1Lux/F2.0(Color), 0Lux/F2.0(IR on)
IR Distance: 1PC up to 10m
Warning Light: 1
Lens: 2.8mm,F 1.85±10%
Angle of View: H:103°
Pan/Tilt Range: Pan:0° ~360° ;Tilt:-10° ~90° ;Rotation:0° ~360°
Streaming Capability: 2 Streams
Resolution:
1080P(1920×1080)/1.3M(1280×960)/
720P(1280×720)/VGA(640 ×480)/
QVGA(320×240)
Frame Rate: 1080P(1~25fps)
VGA/QVGA(1~25fps)
Bit Rate: 8K ~ 8Mbps
Day/Night Auto(ICR) / Color / B/W
BLC Mode BLC / DWDR
White Balance: Auto/Outdoor/Manual
Noise Reduction: 3D DNR
Motion Detection: Off / On
Smart IR: Support
Privacy Masking: Off / On (4 Area, Rectangle)
Compression: G.711
Ethernet: RJ-45 (10/100Base)
Wi-Fi: 2.4GHz & 5GHz Wi-Fi(IEEE802.11a/b/g/n/ac) 10m
Protocol: TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
Streaming Method: Unicast
Max. User Access: 10 Users
Edge Storage: Micro SD Card (up to 128GB)
Local: PC for instant recording
Smart Phone: iOS, Android
Audio Interface: Built-in Mic & Speaker
Alarm: 1/1,PIR
Power Supply: DC12V/POE
Power Consumption: ≤3W
Operating Conditions: -10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH
Strorage Conditions: -10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH

Effective Pixels
1920(H) x 1080(V)
Image Sensor
1/2.8" 2 Megapixel progressive CMOS
Min. Illumination
0.05Lux/F2.0(Color), 0Lux/F2.0(IR on)
IR Distance
up to 10m
IR LED
12
Warning Light
1
Lens Type
Fixed
Focal Length
2.8mm
Max. Aperture
F No. 2.0±10%
Wide Dynamic Range
WDR
Noise Reduction
3D DNR
Alarm
1/1,PIR
Operating Temperature /Humidity-10°C ~ +45°C (14°F ~ +113°F) / Less than 95% RH Power Supply
DC12V/POE
Dimensions
63*120*33mm

●High quality imaging with progressive scan CMOS
●Real time
●Support SMART H.265/H.264 coding
●Up to 20M IR distance
●3D DNR, true WDR, HLC, BLC
●Built-in micro SD card slot, up to 256GB
●1CH audio input; 1CH audio output
●DC12V/PoE power supply
●P2P function optional
●Support three streams
●Support mobile surveillance by smart phones
●Intelligent analytics: Perimeter Intrusion Detection/Line Crossing Detection/Face
Detection/Face Recognition /Human Detection/Vehicle Detection

●High quality imaging with progressive scan CMOS
●Real time
●Support SMART H.265/H.264 coding
●Up to 45M IR distance
●motorized 4X zoom lens
●3D DNR, true WDR, HLC, BLC
●Built-in micro SD card slot, up to 256GB
●1CH audio input; 1CH audio output
●DC12V/PoE power supply
●IP67
●P2P function optional
●Support three streams
●Support mobile surveillance by smart phones
●Intelligent analytics: Perimeter Intrusion Detection/Line Crossing Detection/Face Detection/Face Recognition /Human Detection/Vehicle Detection

Video CompressionI H.265/H.264
ResolutionI 2MP 1920(H)×1080(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination: Color 0.01lux @ F1.2(AGC ON)
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.7 ~ 12 mm (Motorized)
F No.: F 1.6 ±5%
Day & Night: IR cut filter with auto switch
WDR: 120dB WDR
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: Main, Sub, Moblie
Frame Rate;
Mainstream:
1080P(1920x1080),
960P(1280x960),
720P(1280x720)
Substeam:
720P(1280x720),
VGA(640x480),QVGA(320x240)
Mobilestream:
VGA(640x480),QVGA（320x240）
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness: adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Video Analytics: Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection,Cross Counting.
DEEP LEARNING:Face Detection,
Face Recognition /Human Detection/Vehicle Detection(New products coming soon)
Protocols: TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
System Compatibility: ONVIF( Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led &IR Range: 20pcs(SMD) Up to30m
SD storage: yes
Alarm Trigger: yes
Audio: yes
Video Output: BNC output
Reset Button: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: ≤ 7.5W
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Video CompressionI H.265/H.264
ResolutionI 5MP 2592(H)×1944(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination: Color 0.03lux @ F1.2(AGC ON)
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.7 ~ 13.5 mm (Motorized)
F No.: F 1.6 ±5%
Day & Night: IR cut filter with auto switch
WDR: 120dB WDR
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: Main, Sub, Moblie
Frame Rate;
Mainstream:
5MP(2592×1944),
4MP(2592x1520)
3MP(2048x1520),
1080P(1920x1080),
960P(1280x960),
720P(1280x720)
Substeam:
720P(1280x720),
VGA(640x480),QVGA(320x240)
Mobilestream:
VGA(640x480),QVGA（320x240）
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness: adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Video Analytics: Perimeter Intrusion Detection, Line Crossing Detection, Sationary Object Detection, Pedestrian Detection,Cross Counting.
DEEP LEARNING:Face Detection,
Face Recognition /Human Detection/Vehicle Detection(New products coming soon)
Protocols: TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
System Compatibility: ONVIF( Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led &IR Range: 20pcs(SMD) Up to30m
SD storage: yes
Alarm Trigger: yes
Audio: yes
Video Output: BNC output
Reset Button: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: ≤ 7.5W
Storage Temperature: -30～+60°C
Operating Temperature: -30～+55°C

Imaging Device:1/2.8"
Effective Pixels: 2MP1920(H)×1080(V)
Scanning System: Progressive CMOS
Min. Illumination: Color 0.05lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Lens: Type
Focal Length (Zoom Ratio): 2.8mm
Max. Aperture Ratio: F No. 1.6±5%
Angular Field of View: Horizontal:107°, Vertical:57°, Diagonal:128°
Min. Object Distance: 0.2M
Lens Type: Fixed(M12)
IR Viewable Length: Up to 30m
Camera Title: On/Off
Day & Night: IR cut filter with auto switch（Day/Night/Auto/Schedule）
Backlight Compensation: Off/On (5 Zone)
Wide Dynamic Range: DWDR
Digital Noise Reduction: 3D DNR
Motion Detection: Off/On (8 Level)
Privacy Masking: Off/On (4 Zone, Rectangle)
Gain Control: Auto
White Balance: Auto/Manual/Indoor
Electronic Shutter Speed: 1/5 ~ 1/20000s
Flip / Mirror Flip/Rotation
On-Board Storage: Micro SD slot, up to 256GB
Alarm: NA
Built in: Mic NA
Hardware Reset: Yes
Smart Feature: SMD
Ethernet: RJ45(10/100BASE-T)
Video Compression Format: H.265/H.264
Max. Resolution;
"Main Stream: 1080P(1920x1080)
Sub Steam: VGA(640x480)"
Max. Framerate: "50Hz: 25fps (1920x1080,640x480)
60Hz: 30fps (1920x1080,640x480)"
Video Quality Ajustment: 8Kbps ~ 8Mbps
Bitrate control method: CBR/VBR
Streaming Capability: Dual-Stream(Main/Sub)
IP IPv4
Protocol: "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP"
Security: IP address filter;complicated password;Authenticated username and password
Streaming Method: Unicast/Multicast
Max. User Access: Max 7 (admin+user)
Application Programming Interface: ONVIF( Profile S/G/T, 18.12)
Web Viewer "IE8,9,10,11, Chrome 44/lower, Firefox 51/lower,
Safari 11/lower,"
Operating Temperature / Humidity -30～+60°C/less than ≤ 95% RH
Ingress Protection IP66
Input Voltage / Current D12V/POE(IEEE802.3af)
Power Consumption TBD
Color / Material White/Metal
Dimension (WxHxD) Ø69.3 X 150.8mm
Weight appr. 320g

DSP: HI3516AV300
Resolution: 5MP 2592(H)×1944(V)
Image Sensor: 1/2.8" Progressive CMOS
Min. Illumination Color: 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.7 ~ 13.5mm (Motorized) H.FOV: 103 ~ 28°
Lens: mount ∮14
F No. F No.: W:1.6--T:3.1±5%
Day & Night: IR cut filter with auto switch（Day/Night/Auto/Schedule）
Digital noise reduction: 3D DNR
WDR 120 dB
Video Compression: H.265/H.265+/H.264/H.264+
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: yes
Audio format: G.711A/G711U/ADPCM/G726 16k/G726 24k/G726 32k/G726 40k
Resolution: "Mainstream（1~30fps default 30fps): 5MP (2592x1944),4MP(2592x1520),
3MP(2304x1296)(2048x1535):1080P(1920x1080), 720P(1280x720),
Substeam: 720P(1280x720), VGA(640x480),QVGA(320x240)
Mobilestream: VGA(640x480), QVGA（320x240）"
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness: adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Smart Feature: Face Detection, Human/Vehicle Detecion
Protocols:TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
System Compatibility: ONVIF( Profile S, Profile G)
Interface: RJ45 10M / 100M Ethernet interface x1
Led: 4 pcs (Array)
IR Range: Up to 40 m
SD storage: yes（Micro SD/SDHC/SDXC slot, up to 128 GB）
Alarm Trigger: 1 input / 1 output
Audio: 1 input / 1 output (RCA)
Video Output: NA
Reset Button: yes
PoE: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: TBD
Dimension: 87.44*242.12
Weight appr.: 783g
Storage Temperature: -30～+60°C/less than ≤ 95% RH
Operating Temperature: -30～+55°C

Imaging Device 1/2.7"
Effective Pixels 8MP 3840(H)×2160(V)
Min. Illumination Color 0.009lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON
Focal Length 3.6mm
Day & Night IR cut filter with auto switch（Day/Night/Auto/Image/Schedule）
Wide Dynamic Range DWDR
Digital Noise Reduction 3D DNR
Smart Feature PID,LCD,PD/VD,SOD,CC,CD,QD,Heat MAP,RSD,FD（detection）
Max.Resolution 8MP(3840x2160)@20fps
Video Quality Ajustment 8Kbps ~ 16Mbps
Operating Conditions -35～+60°C/less than ≤ 95% RH
Ingress Protection IP67
Input Voltage / Current D12V/PoE(IEEE802.3af)
Material Metal

Main Chipset: Hi3516EV200-QFN88 built in DDR 64MB
Flash: W25N01GVZEIG/WSON8(SPI NAND Flash)
Resolution: 2MP 1920(H)×1080(V) HI3516EV200
Image Sensor: 1/2.7" Progressive CMOS SC2238H
Min. Illumination Color: 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter: 1/5 ~ 1/20000s
Slow shutter: Support
Lens: 2.8mm Horizontal:107°, Vertical:57°, Diagonal:128°
F No. F No. 1.6±5%
Day & Night IR cut filter with auto switch（Day/Night/Auto/Schedule）
Digital noise reduction: 3D DNR
WDR DWDR
Video Compression H.265/H.264
Video bit rate 8Kbps ~ 8Mbps
Multi-Stream Dual
Resolution "Main Stream
1080P(1920x1080),
Sub Steam
VGA(640x480)"
Image Settings: Flip，Rotation， Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC Support
Privacy Mask Support
Smart Feature SMD
Protocols "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP"
System Compatibility ONVIF( Profile S, Profile G)
Interface RJ45 10M / 100M Ethernet interface x1
Led 2 pcs(Array)
IR Range Up to 30m
SD storage Yes
Alarm Trigger no
Audio no
Video Output: no
Reset Button Yes
PoE Yes
Water Proof IP 66
Power Supply DC 12V/POE
Dimension Φ100*90mm
Weight 478g
Storage Temperature -30～+60°C
Operating Temperature -30～+55°C

Resolution 2MP 1920(H)×1080(V)
Image Sensor 1/2.8" Progressive CMOS
Min. Illumination Color 0.01lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter 1/5 ~ 1/20000s
Slow shutter Support
Lens 2.8mm H.FOV: 107°
F No. F No. 1.6±5%
Day & Night IR cut filter with auto switch（Day/Night/Auto/Schedule）
Digital noise reduction: 3D DNR
WDR 120 dB
Video Compression H.265/H.264
Video bit rate 8Kbps ~ 8Mbps
Triple Stream yes
Resolution "Mainstream（default 30fps）
1080P(1920x1080), 720P(1280x720),
Substeam（default 10fps )
720P(1280x720),VGA(640x480),
QVGA(320x240)
Mobilestream（default 10fps）
VGA(640x480), QVGA（320x240）"
Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC Support
ROI Support
Privacy Mask Support
Smart Feature Face Detection, Human/Vehicle Detecion
Protocols "TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,"
System Compatibility ONVIF( Profile S, Profile G,ProfileT)
Interface RJ45 10M / 100M Ethernet interface x1
IR Led 2pcs(Array)
IR Range Up to 30m
SD storage yes
Alarm Trigger no
Audio no
Video Output: no
Built in MIC yes
Reset Button yes
PoE yes
Water Proof IP 66
Power Supply DC 12V/POE
Consumption POE Consumption : 48V, 3.2W (daytime)；5.8W（night time）
Dimension Ø100*90mm
Weight 320g
Storage Temperature -30～+60°C/less than ≤ 95% RH
Operating Temperature -30～+55°C

Resolution: 5MP 2160(H)×2160(V)
Image Sensor: 1/2.9" Progressive CMOS
Min. Illumination Color: 0.1lux @ F1.2(AGC ON) ; B/W 0 lux @ IR ON
Shutter: 1/5 ~ 1/20000s
Lens: 1.1mm ,Angle of view: 360°
F No.: F 2.0 ±5%
Day & Night: IR cut filter with auto switch
WDR Digital: WDR
Video Compression: H.265/H.264
Video bit rate: 8Kbps ~ 8Mbps
Triple Stream: yes
Frame Rate "Mainstream: 5MP (2160×2160), 1520x1520, 1080x1080, 720x720
Substeam: 720x720, 480x480, 240x240
Mobilestream: 480x480, 240x240"
Image Settings: Rotate mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC Support
ROI Support
Video Analytics NA
Protocols TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,SMTP,NTP,UPnP,SNMP,HTTPS,FTP
System Compatibility ONVIF( Ver 2.6)
Interface RJ45 10M / 100M Ethernet interface x1
Led 3pcs(SMD)
IR Range Up to 5m
SD storage Yes
Alarm Trigger Yes
Microphone Yes
Speaker Yes
BNC Video Output Yes
Reset Button Yes
PoE yes
Water Proof IP 66
Power Supply DC 12V/POE
Consumption ≤ 5W
Dimension Ø120*55mm
Weight appr 400g
Storage Temperature -30～+60°C
Operating Temperature -30～+55°C

Image Settings: Flip，Rotation，Corridor mode, Saturation, Brightness, Contrast, Hue, Sharpness adjustable
BLC: Support
ROI: Support
Privacy Mask: Support
Smart Feature: Face Detection, Human/Vehicle Detecion
Protocols: TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,PPPoE,SMTP,NTP,UPnP,SNMP,HTTPS,FTP,
System Compatibility: ONVIF( Profile S, Profile G,ProfileT)
Interface: RJ45 10M / 100M Ethernet interface x1
IR Led: 2pcs(Array)
IR Range: Up to 30m
SD storage: yes
Alarm Trigger: no
Audio: NO
Video Output: no
Reset Button: yes
PoE: yes
Water Proof: IP 66
Power Supply: DC 12V/POE
Consumption: TBD
Dimension: 70.9*150.8mm
Weight appr.: 370g
Storage Temperature: -30～+60°C/less than ≤ 95% RH
Operating Temperature: -30～+55°C

Image Sensor: Panasonic 34227
Effective Pixels: 1080P(1920X1080)
Electronic Shutter: 1/25s ~ 1/30000s
Day & Night: ICR
Min. Illumination: 0lux (IR ON)
Image Settings: Exposure Mode(Auto/Iris Priority/Shutter Priority/Manual),Sharpness, Saturation, Brightness & Contrast Adjustable, AWB, AGC Adjustable
WDR Range: Digital WDR
Noise Reduction: 2D/3D-DNR
Image Orientation: Mirror/Flip
Privacy Zone: Yes
Motion Detection: Yes
Compression:
Video Compression: Image Quality
Resolution: 50HZ:25fps(1920x1080) 60HZ:30fps(1920x1080)
Bit rate: 32kbps-8Mbps
Encode Mode: VBR/CBR
Image Quality: Six levels under VBR; Free adjustment under CBR
Housing:
Lens: 5.1-51mm
Iris: Auto Iris
Water-proof: IP66
Bracket: Wall Bracket
Dimensions: 144mm×94mm×133mm（L×W×H）
Weight: 1.3kg
PTZ:
Optical Zoom: 10X
IR Distance: Max.80m
Pan Rotation Range: 0〫~260〫
Tilt Rotation Range: -5〫~55 〫
Pan Speed: 0.5~12 〫/s
Tilt Speed: 0.5~12 〫/s
Preset Position: 256
Connectivity:
Network: RJ45
Power: DC 12V
SD Card Slot: Support
Network:
Remote Monitoring: IE Browsing, CMS 3 Control Software
User Access: Supports simultaneous monitoring for up to 4 users with multi-stream real time transmission
Network Protocol: TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP
ONVIF: Support

ONY IMX 322 SENSOR 100M IR DISTANCE
20x OPTICAL ZOOM
16x DIGITAL ZOOM 1080
AUTO TRACKING FUNCTION WITHOUT WIPER
Image Sensor 1/2.8" Progressive Scan CMOS
Resolution 1080P(1920X1080)
Mini Illumination 0.05 Lux (Colour) (F1.6,AGC ON)
0.01 Lux (B/W) (F1.6,AGC ON)
Lens f=4.7~94 mm
IRIS F1.6~F3.5 Angle of View 61.4°(wide) ~ 2.9°(tele)
Min Object Distance 10mm~1500mm
Optical Zoom 20x Solution Ambarella S2LM
Video Coding H.264 Main Profile MJPEG/JPEG Baseline Dual-stream Support Image Resolution Main stream：1920x1080 1080P Second stream：704x576 D1 Audio Coding G.711ulaw ONVIF
Protocol Support NETWORK PROTOCAOL TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, UPnP, FTP, IPv6 (SIP,SRTP,optional)
IR Distance 100m Pan Range 360°

STAR LIGHT
COLOR 0.005Lux@F1.6; 150M
IR DISTANCE, 30x ZOOM
16x DIGITAL ZOOM
1080P
AUTO RACKING FUNCTION
WITHOUT WIPER Image Sensor 1/2.8" Progressive Scan CMOS
Resolution 1080P(1920X1080)
Mini Illumination 0.005 Lux (Colour)@F1.6
Lens f=4.3~129 mm IRIS F1.6~F5.0 Angle of View 65.1°(wide) ~ 2.34°(tele)
Min Object Distance 10mm~1500mm Optical Zoom 30x Electronic Shutter 1/1~1/30,000s Solution Ambarella S2LM
Video Coding H.264 Main
Profile MJPEG/JPEG Baseline Dual-stream
Support Image Resolution Main stream：1920x1080 1080P Second stream：704x576 D1 Audio Coding G.711ulaw
ONVIF Protocol Support NETWORK PROTOCAOL TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, UPnP, FTP, IPv6 (SIP,SRTP,optional)
IR Distance 150m
Pan Range 360° IP66, the secondary lightning protection, 3000V anti-surge design

Video Compression: H.264
Day / Night Mode: Color during day, switches to B&W at night
Maximum Frame Rate: 30fps
Maximum Streams: 2 Simultaneous Streams
Image Sensor: 1/4" Mega Pixel Color CMOS sensor
Max. Resolution: 1280x720 pixels (Mega pixels)
Lens: 3.6mm fixed, F1.6
ICR Control: Yes
Viewing Angle: 65°
Min. Illumination: 0.1 Lux
Pan/Tilt Range: Horizontal: 355° & Vertical 120°
Night Vision: Distance: up to 10M / 33ft
Illumination: Infread LED
Audio Input: 1 Built-in Microphone
Audio Output: 1 Built-in Speaker (8Ω0.25W)
Compression: G.711
LAN Interface: RJ-45, 10/100Mbps
Network Type: TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,RTSP
WIFI: IEEE 802.11b/g/n
ONVIF: Support
ONVIF: 2.0
Plug & Play: Easy to setup, KViewCam APP
Maximun Online Visitor: 3 visitors simultaneously
Motion Detection: Yes
Alarm I/O: N/A
External Storage: MicroSD Card (Capacity supports up to 64GB)
Indoor / Outdoor: Indoor
Operating Temperature: 0°C ~ 50°C
Operating Humidity: 20% ~ 85%, non-condensing
Power Consumption: DC 5V/2A
Dimension (LxWxH): 130 x 105 x 135mm
Weight: 303g
Operating System: Microsoft Windows XP / Vista / 7 / 8
Browser: Internet Explorer 6 or above , Google Chrome , Mozilla Firefox , Mac Safari

Imaging Device: 1/2.7" Progressive CMOS
Scanning System: Progressive Scanning
Min. Illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Video Output: BNC
Resolution: 2MP 1920（H）×1080（V） 5MP 2592（H）×1944（V)
Max, Framerate
Max. Aperture Ratio F1.0
Lens Type/ Focal Length Fixed lens / 3.6mm
Audio Audio over coaxial
Audio Range 7m
IR Distance/ Warm Light Viewable Length 20-30m
On Screen Display English
Day & Night Color / Ext / B/W
Backlight Compensation Off / User BLC
Wide Dynamic Range N/A
Digital Noise Reduction 2D DNR
Gain Control Auto
White Balance ATW
Electronic Shutter Speed Auto
Reverse Mirror
Video Transmission Distance MAX 300M （ Cable : 5C 2V）
Operating Temperature / Humidity -30°C ~ 55°C / 90%
Ingress Protection IP66
Input Voltage/Current 12V DC
Power Consumption IR OFF ≤ 0.5W, IR ON ≤ 3.5W
Color / Material Metal

Imaging Device: 1/2.8" Progressive CMOS
Scanning System: Progressive Scanning
Min. Illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Video Output: BNC
Resolution: 2MP 1920（H）×1080（V）
Max, Framerate: AHD/TVI/CVI: P/@25fps N/@30fps CVBS: 960H
Max. Aperture Ratio: F1.8-3.3
Lens Type/ Focal Length: Motorized lens / 2.8-12mm /2.7-13.5mm
Audio: N/A
Audio Range: N/A
IR Distance: 35m
On Screen Display: English
Day & Night: Ext / Color / B/W
Backlight Compensation: Off / User BLC
Wide Dynamic Range: WDR (Off/On)
Digital Noise Reduction: 3D DNR
Gain Control: Auto
White Balance: ATW
Electronic Shutter: Speed Auto
Reverse: Mirror
Video Transmission Distance: MAX 300M （ Cable : 5C 2V）
Operating Temperature / Humidity: -30°C ~ 55°C / 90%
Ingress Protection: IP66
Input Voltage/Current: 12V DC
Power Consumption: IR OFF ≤ 2W, IR ON ≤ 6.5W
Color / Material: Metal

RAYSHARP 2MP RS-CA223
TUG-36W-M 2MP AOC Analog bullet camera, plastic, 3.6mm

Imaging Device: 1/3" Progressive CMOS
Scanning System: Progressive Scanning
Min. Illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Video Output: BNC
Resolution: 2MP 1920（H）×1080（V)
Max. Aperture: Ratio F1.0
Lens: Type/ Focal Length Fixed lens / 3.6mm
Audio: Audio over coaxial
Audio Range: 7m
IR Distance/ Warm Light Viewable Length: 20-30m
On Screen Display: English
Day & Night Color / Ext / B/W
Backlight Compensation Off / User BLC
Wide Dynamic Range D-WDR (Off/On)
Digital Noise Reduction 2D DNR
Gain Control Auto
White Balance ATW
Electronic Shutter Speed Auto
Reverse Mirror
Video Transmission Distance MAX 300M （ Cable : 5C 2V）
Operating Temperature / Humidity -30°C ~ 55°C / 90%
Ingress Protection IP66
Input Voltage/Current 12V DC
Power Consumption IR OFF ≤ 0.5W, IR ON ≤ 3.5W
Color / Material Metal

Imaging Device: 1/3" Progressive CMOS
Scanning System: Progressive Scanning
Min. Illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Video Output: BNC
Resolution: 2MP 1920（H）×1080（V）
Max, Framerate: AHD/TVI/CVI: P/@25fps N/@30fps
Max. Aperture Ratio F1.0
Lens Type/ Focal Length Fixed lens /2.8mm
Audio Audio over coaxial
Audio Range 7m
IR Distance/
Warm Light Viewable Length 20-30m
On Screen Display English
Day & Night Color / Ext / B/W
Backlight Compensation Off / User BLC
Wide Dynamic Range D-WDR (Off/On)
Digital Noise Reduction 2D DNR
Gain Control Auto
White Balance ATW
Electronic Shutter Speed Auto
Reverse Mirror
Video Transmission Distance MAX 300M （ Cable : 5C 2V）
Operating Temperature / Humidity -30°C ~ 55°C / 90%
Ingress Protection IP66
Input Voltage/Current 12V DC
Power Consumption IR OFF ≤ 0.5W, IR ON ≤ 3.5W
Color / Material Metal

Image Sensor: 2.0MP 1/2.7"
Effective Pixels: 1920 (H) x1080 (V)
Video Frame Rate: 25fps (PAL), 30fps(NTSC)
Noise Reducation: 2DNR
Lens: 3.6mm/6mm optional
Synchronization: Internal
Video Output: 1 channel BNC
Day/Night: IR cut filter with auto switch
IR Range: 3.6mm Lens: 10m / 6mm Lens: 15m
Power Supply: DC12V±10%
Power Consumption: Max 4.2W
Working Environment: -10°C~+55°C/ Less than 95%RH

Image Sensor 2.0MP 1/2.7"
Effective Pixels 1920 (H) x1080 (V)
Video Frame Rate 25fps (PAL), 30fps(NTSC)
Noise Reducation 2DNR
Lens: 3.6mm/6mm optional
Synchronization: Internal
Video Output: 1 channel BNC
Day/Night: IR cut filter with auto switch
IR Range: 3.6mm Lens: 10m / 6mm Lens: 15m
Power Supply: DC12V±10%
Power Consumption: Max 4.2W
Working Environment: -10°C~+55°C/ Less than 95%RH

1/2.7" CMOS, Metal bullet camera, 30pcs IR leds
25-30m night vision, varifocal 2.8-12mm

Image Sensor: SC2238 1/2.7" Progressive CMOS
Signal System: PAL/NTSC
Frame Rate: "AHD/TVI/CVI: P/@25fps N/@30fps
CVBS: 960H"
Resolution: 2MP 1920（H）×1080（V）
Min.illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Shutter Time: 1/15 s to 1/50,000 s
Lens: 2.8 mm
Horizontal: Field of View H.FOV:102.94°(2.8)
Day & Night: IR cut filter
IR Cut Filter: YES,850nm
Synchronization Internal: synchronization
Dwdr: support
AGC: YES
Day/Night: Mode EXT/Auto/Color/BW (Black and White)
white balance Auto/Manual
BLC: YES
S/N: Ratio 40dB
OSD: support
Video Output: Termination 1-channel BNC video output
Swaitch Button: AHD/TVI/CVI/CVBS
IP Rating: IP66
Power Supply: 12V
Power Consumption: MAX 3W
Ir Rannge: up to 20M
Communication: Up the coax, Protocol

Image Sensor: SC2235H 1/2.7" Progressive CMOS
Signal System: PAL/NTSC
Frame Rate: "AHD/TVI/CVI: P/@25fps N/@30fps
CVBS: 960H"
Resolution: 2MP 1920（H）×1080（V）
Min.illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Shutter Time: 1/15 s to 1/50,000 s
Lens: 2.8-12 mm fixed lens
Horizontal Field of View: H.FOV:113.54°(W)—29.76°(T)(2.8-12)
Day & Night: IR cut filter
IR Cut Filter: YES,850nm
Synchronization Internal: synchronization
Dwdr: support
AGC: YES
Day/Night Mode: EXT/Auto/Color/BW (Black and White)
White balance: Auto/Manual
BLC: YES
S/N Ratio: 40dB
OSD: support
Video Output Termination: 1-channel BNC video output
Swaitch Button: AHD/TVI/CVI/CVBS
IP Rating: IP66
Power Supply: 12V
Power Consumption: MAX 3W
Ir Rannge: up to 35M
Communication: Up the coax, Protocol

Image Sensor: SC2232 1/2.9" Progressive CMOS
Signal System: PAL/NTSC
Frame Rate "
AHD/TVI/CVI: P/@25fps N/@30fps
CVBS: 960H "
Resolution: 2MP 1920（H）×1080（V）
Min.illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Shutter Time: 1/15 s to 1/50,000 s
Lens: 3.6 mm
Horizontal Field of View: H.FOV:87.13°(3.6)
Day & Night: IR cut filter
IR Cut Filter: YES,850nm
Synchronization Internal: synchronization
Dwdr: support
AGC: YES
Day/Night Mode: EXT/Auto/Color/BW (Black and White)
White balance: Auto/Manual
BLC: YES
S/N Ratio: 40dB
OSD: support
Video Output Termination: 1-channel BNC video output
Swaitch Button: AHD/TVI/CVI/CVBS
IP Rating: IP66
Power Supply: 12V
Power Consumption: MAX 3W
Ir Rannge: up to 15M
Communication: Up the coax, Protocol

Image Sensor: 5.0MP 1/2.7"
Effective Pixels: 2592 (H) x 1944 (V)
Video Frame Rate: 20fps (PAL), 20fps(NTSC)
Noise Reducation: 2DNR
Lens: 3.6mm/6mm optional
Synchronization: Internal
Video Output: 1 channel BNC
Day/Night: IR cut filter with auto switch
IR Range: 3.6mm Lens: 10m / 6mm Lens: 15m
Power Supply: DC12V±10%
Power Consumption: Max 4.2W
Working Environment: -10°C~+55°C/ Less than 95%RH

Image Sensor: 2.0MP 1/2.7"
Effective Pixels: 1920 (H) x1080 (V)
Video Frame Rate: 25fps (PAL), 30fps(NTSC)
Noise Reducation: 2DNR
Lens: 3.6mm/6mm optional
Synchronization: Internal
Video Output: 1 channel BNC
Day/Night: IR cut filter with auto switch
IR Range: 3.6mm Lens: 10m / 6mm Lens: 15m
Power Supply: DC12V±10%
Power Consumption: Max 4.2W
Working Environment: -10°C~+55°C/ Less than 95%RH

Image Sensor: SC2238 1/2.7" Progressive CMOS
Signal System: PAL/NTSC
Frame Rate: "AHD/TVI/CVI: P/@25fps N/@30fps
CVBS: 960H"
Resolution: 2MP 1920（H）×1080（V）
Min.illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Shutter Time: 1/15 s to 1/50,000 s
Lens: 2.8 mm
Horizontal Field of View: H.FOV:102.94°(2.8)
Day & Night: IR cut filter
IR Cut Filter: YES,850nm
Synchronization Internal: synchronization
Dwdr: support
AGC: YES
Day/Night Mode: EXT/Auto/Color/BW (Black and White)
White balance: Auto/Manual
BLC: YES
S/N Ratio: 40dB
OSD: support
Video Output Termination: 1-channel BNC video output
Swaitch Button: AHD/TVI/CVI/CVBS
IP Rating: IP66
Power Supply: 12V
Power Consumption: MAX 3W
Ir Rannge: up to 20M
Communication: Up the coax, Protocol

Image Sensor: SC2232 1/2.9" Progressive CMOS
Signal System: PAL/NTSC
Frame Rate "
AHD/TVI/CVI: P/@25fps N/@30fps
CVBS: 960H "
Resolution: 2MP 1920（H）×1080（V）
Min.illumination: 0.05lux@F1.2(AGC ON),0Lux with IR ON
Shutter Time: 1/15 s to 1/50,000 s
Lens: 3.6 mm
Horizontal Field of View: H.FOV:87.13°(3.6)
Day & Night: IR cut filter
IR Cut Filter: YES,850nm
Synchronization Internal: synchronization
Dwdr: support
AGC: YES
Day/Night Mode: EXT/Auto/Color/BW (Black and White)
White balance: Auto/Manual
BLC: YES
S/N Ratio: 40dB
OSD: support
Video Output Termination: 1-channel BNC video output
Swaitch Button: AHD/TVI/CVI/CVBS
IP Rating: IP66
Power Supply: 12V
Power Consumption: MAX 3W
Ir Rannge: up to 15M
Communication: Up the coax, Protocol

Image Sensor: 5.0MP 1/2.7"
Effective Pixels: 2592 (H) x 1944 (V)
Video Frame Rate: 20fps (PAL), 20fps(NTSC)
Noise Reducation: 2DNR
Lens: 3.6mm/6mm optional
Synchronization: Internal
Video Output: 1 channel BNC
Day/Night: IR cut filter with auto switch
IR Range: 3.6mm Lens: 10m / 6mm Lens: 15m
Power Supply: DC12V±10%
Power Consumption: Max 4.2W
Working Environment: -10°C~+55°C/ Less than 95%RH

2592 (H) ×1944 (V)
Night Vision(metres) 35 m /
Weather Proof Rating (IP Standard) IP 66
Lens (mm) 2.8-12mm

2 Megapixel
1/2.7" CMOS
1080P30FPS（NTSC)
1080P25FPS（PAL）
3.6 mm/F2.0 fixed
lens / M12

Image Sensor 1/3" 2-Megapixel High Quality
CMOS Image Sensor
Horizontal Resolution 1920x1080
Electronics Shutter NTSC 1/60-1/100,000(sec) PAL 1/50-1/100,000(sec)
Lens 3.6mm
Viewing Angle 75 Degrees
Video Output 1.0VP-P, 75 S/N Ratio More than 48dB (AGC OFF)
Day / Night Mode
Color during day / switches to B&W at night
Minimum Illumination While Infrared LED on "0" lux Gain Control Auto Backlight Compensation Auto Night Vision
Night Vision Distance 30m
Illumination Infrared Array
Infra-Red Wavelength 850nmInfra-Red
LED Life 10,000hrs

Sensor type: CMOS
Sensor resolution: 2 Mpx
Features: Water resistance
Max. video resolution: Full HD (1920×1080)
Video with Sound: No Sound
Colour: White
Depth: 14 cm
Width: 14 cm
Height: 10.5 cm

1080P High Resolution
3.6mm Fixed Lens
Long range night vision up to 30 meters for day & night surveillance
The weatherproof metal casing can be used in both indoor & outdoor applications
1/3" 2-Megapixel Image sensor
75 Degrees Viewing Angle
Night Vision

2 Mega Pixel (1080P) High Quality CMOS
Image Sensor - Night vision 100ft/30m
Outdoor/Indoor Camera
1080P High Resolution
3.6mm Fixed Lens
Long range night vision up to 30 meters
The weatherproof metal casing can be used in both indoor &amp; outdoor applications

Alarm Action: Local Alarm
Audio Output: None
Brand Name: tysvance
Connectivity: Closed System/CCTV Wired
gmtCreate: 1463295600
High Definition: 2.0 Megapixels
Installation: Side
IR: 4 high power array LEDs with IR
IR Distancem: Up to 80m
is customized: Yes
Lens mm: 5.1-51mm
Model Number: DM-SCB415AI-V10
Network Interface: None
Pan/Tilt: Pan: 260degree,Tilt: 55degree
Pixel: 2MP
Power ConsumptionW: 18W
Power Supply: Normal
Power SupplyV: DC 12V
Sensor: CMOS
Sensor Brand: Sony
Special Features: Waterproof / Weatherproof
Storage: None
Style: Bullet Camera
Supported Operating Systems: No
Technology: Infrared
TF Card: None
Video Output: BNC
Wall Bracket: Side
Тип: AHD Camera
Color: WHITE

SONY IMX 322
100M IR DISTANCE
20x OPTICAL ZOOM
Resolution 1080P(1920X1080)
Lens f=4.7~94 mm
IRIS F1.6~F3.5
Angle of View 61.4°(wide) ~ 2.9°(tele)
Min Object Distance 10mm~1500mm
Optical Zoom 20x
ONVIF Protocol Support NETWORK PROTOCAOL P/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, UPnP, FTP, IPv6 (SIP,SRTP,optional)

SONY IMX322 SENSOR
150M IR DISTANCE
20x OPTICAL ZOOM
Resolution 1080P(1920x1080)
Optical Zoom 20X optical zoom IRIS Fix
IR-CUT Auto/Manual
Electronic Shutter 1/1~1/10,000s
Min illumination 0.05 Lux (Colour)
0.01 Lux (B/W)
Focal length 4.9~98mm
Day/Night
Noise Reduction 2DNR/3DNR
Pan Range 360°
Tile Range Range -10°~90°

Video Compression: H.265/H.264
Video System: NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 4CH inputs / VGA and HDMI output
IP Video Input 2ch,(only IP up to 6ch)
Composite Video: Input up to 6ch (Analog video + IP video)
Audio input /output: 4CH inputs /1CH output(RCA)
Display resolution: "Analog : 5MP-Lite:20fps
4MP-Lite:30 fps
3MP:18fps
1080P/720P/960H:30fps
IP : 5MP/4MP/3MP1080P/720P"
Feature: 1/4/6/S.E.Q.
Record resolution: "Analog : 5MP-Lite/4MP-Lite/3MP/1080P/720P/960H
IP : 5MP/4MP/3MP1080P/720P"
Speed: "Analog : 5MP-Lite:12fps (each ch)
4MP-Lite:14fps(each ch)-
3MP:9fps(each ch)
1080P:13fps(each ch)
720P:PAL:25fps(each ch)/NTSC::30fps(each ch)
IP : PAL:25fps(each ch)/NTSC: 30fps(each ch) "
"IP-Recording Bandwidth
(Maximum input Bandwidth) " 8Mbps ~24Mbps( default is 8Mbps, decrease one Analog channel can increase 4Mbps )
Maximum output Brandwidth: 48Mbps
Maximum decode performance: 1080P:52fps
Recording Mode: Continuous/Manual/Motion detect
Synchronous Playback: 4CH
Network Type: Lan, DHCP, and DDNS
HDD interface: 1SATA HDD, up to 6TB
Multiplex Operation: live display, record, playback, backup and network
USB 2xUSB(for mouse and backup/upgrade)
Sensor & Alarm I/O no
PTZ Control yes (RS485)
Mobile Surveillance: Support Mobile Phones based on iPhone and Android operation system
VGA/HDMI 1024*768,1280*720,1280*1024,1440*900,1920*1080(1080P),2560*1440(2K),3840*2160(4K)
Power Supply: DC 12V/2A
Dimension(WxDxH) 300X227X53mm
Working Temperature: -10°C~+55°C
Working Humidity: 10%~90%

Video Compression: H.265/H.264
Video System: NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 16CH inputs / VGA and HDMI output
IP Video: Input 8ch,(only IP up to 24ch)
Composite Video: Input up to 24ch (Analog video + IP video)
Audio input /output: 16CH inputs /1CH output(RCA)
Display resolution: "Analog : 5MP-Lite:20fps
4MP-Lite:30 fps
3MP:18fps
1080P/720P/960H:30fps
IP : 5MP/4MP/3MP1080P/720P"
Feature
Record resolution "Analog : 5MP-Lite/4MP-Lite/3MP/1080P/720P/960H
IP : 5MP/4MP/3MP1080P/720P"
Speed "Analog : 5MP-Lite:15fps (each ch)
4MP-Lite:18fps(each ch)-
3MP:10fps(each ch)
1080P:15fps(each ch)
720P:PAL:25fps(each ch)/NTSC::30fps(each ch)
IP : PAL:25fps(each ch)/NTSC: 30fps(each ch) "
"IP-Recording Bandwidth
(Maximum input Bandwidth) " 32Mbps ~96Mbps(default is 32Mbps, decrease one Analog channel can increase 4Mbps)
Maximum output Brandwidth: 96Mbps
Maximum decode performance: 1080P:240fps
Recording Mode: Continuous/Manual/Motion detect
Synchronous Playback: 16CH
Network Type: Lan, DHCP, and DDNS
HDD interface: 2SATA HDDs, up to 16TB
Multiplex Operation: live display, record, playback, backup and network
USB 2xUSB(for mouse and backup/upgrade)
Sensor & Alarm I/O 16 inputs /1 output
PTZ Control yes (RS485)
Mobile Surveillance: Support Mobile Phones based on iPhone and Android operation system
VGA/HDMI 1024*768,1280*720,1280*1024,1440*900,1920*1080(1080P),2560*1440(2K),3840*2160(4K)
Power Supply: DC 12V/5A
Dimension(WxDxH): 378x340x50mm
Working Temperature: -10°C~+55°C
Working Humidity: 10%~90%

Video Compression: H.265/H.264
Video System: NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 32CH inputs / VGA and HDMI BNC output
IP Video: Input 4ch
Composite Video: Input up to 36ch (Analog video + IP video)
Audio input /output: 8CH inputs /1CH output(RCA)
Display resolution: "Analog : 5MP-Lite:20fps
4MP-Lite:30 fps
3MP:18fps
1080P/720P/960H:30fps
IP : 5MP/4MP/3MP1080P/720P"
Feature
Record resolution "Analog : 5MP-Lite/4MP-Lite/3MP/1080P/720P/960H
IP : 5MP/4MP/3MP1080P/720P"
Speed: "Analog : 5MP-Lite:12fps (each ch)
4MP-Lite:15fps(each ch)-
3MP:10fps(each ch)
1080P:15fps(each ch)
720P:PAL:25fps(each ch)/NTSC::30fps(each ch)
IP : PAL:25fps(each ch)/NTSC: 30fps(each ch) "
"IP-Recording Bandwidth
(Maximum input Bandwidth) " 16Mbps ~96Mbps(default is 16Mbps, decrease one Analog channel can increase 4Mbps)
Maximum output Brandwidth: 96Mbps
Maximum decode performance: 1080P:480fps
Recording Mode: Continuous/Manual/Motion detect
Synchronous Playback: 16CH
Network Type: Lan, DHCP, and DDNS
HDD interface: 4SATA HDDs, up to 32TB
Multiplex Operation: live display, record, playback, backup and network
USB 2xUSB(for mouse and backup/upgrade)
Sensor & Alarm I/O 16 inputs /1 output
PTZ Control yes (RS485)
Mobile Surveillance: Support Mobile Phones based on iPhone and Android operation system
VGA/HDMI 1024*768,1280*720,1280*1024,1440*900,1920*1080(1080P),2560*1440(2K),3840*2160(4K)
Power Supply: DC 12V/5A
Dimension(WxDxH): 378x326x66mm
Working Temperature: -10°C~+55°C
Working Humidity: 10%~90%

Video Compression: H.264
Video System: NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 16 CH inputs / VGA and HDMI output
Composite Video Input :up to 24ch (Analog video + IP video)
Display resolution : Analog 5MP (20fps)
4MP/3MP(30fps) 1080P/720P/960H IP 4MP/3MP 1080P/720P
Maximum output Brandwidth: 64Mbps
Maximum decode performance: 5MP: 176fps 4MP: 240fps 1080P: 480fps
Synchronous Playback: 16 CH Network Type Lan, DHCP, and DDNS
HDD interface: 2SATA HDDs, up to 12TB PTZ
Control: yes (RS485)
Mobile Surveillance: Support
Mobile Phones: based on iPhone and Android
Operation system VGA/HDMI 1280*1024， 1440*900， 1280*720， 1920*1080 ，1680 * 1050 ，1600*1200， 1920*1200， 2560*1440 , 3840*2160

Video Compression: H.264
Video System: NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 4 CH inputs / VGA and HDMI output
Composite Video Input: up to 6ch (Analog video + IP video)
Display resolution :Analog 5MP (20fps) 4MP/3MP (30fps) 1080P/720P/960H IP:4MP /3MP1080P/720P
Record :Analog

Video Compression: H.265/H.264
Video System: NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 8CH inputs / VGA and HDMI output
IP Video Input: 4ch,(only IP up to 12ch)
Composite Video Input :up to 12ch (Analog video + IP video)
Audio input /output: 4CH inputs /1CH output(RCA)
Display resolution;
Analog : 5MP-Lite:20fps
4MP-Lite:30 fps
3MP:18fps
1080P/720P/960H:30fps
IP : 5MP/4MP/3MP1080P/720P
feature 1/4/6/8/9/S.E.Q.
Record resolution: Analog : 5MP-Lite/4MP-Lite/3MP/1080P/720P/960H
IP : 5MP/4MP/3MP1080P/720P
Speed: Analog : 5MP-Lite:15fps (each ch)
4MP-Lite:18fps(each ch)-
3MP:10fps(each ch)
1080P:15fps(each ch)
720P:PAL:25fps(each ch)/NTSC::30fps(each ch)
IP : PAL:25fps(each ch)/NTSC: 30fps(each ch) "
IP-Recording Bandwidth:
(Maximum input Bandwidth) 16Mbps ~48Mbps( default is 16Mbps, decrease one Analog channel can increase 4Mbps )
Maximum output Brandwidth: 64Mbps
Maximum decode performance: 1080P:120fps
Recording Mode: Continuous/Manual/Motion detect
Synchronous Playback: 8CH
Network Type: Lan, DHCP, and DDNS
HDD interface: 1SATA HDD, up to 6TB
Multiplex Operation: live display, record, playback, backup and network
USB: 2xUSB(for mouse and backup/upgrade)
Sensor & Alarm: I/O no
PTZ Control: yes (RS485)
Mobile Surveillance: Support Mobile Phones based on iPhone and Android operation system
VGA/HDMI 1024*768,1280*720,1280*1024,1440*900,1920*1080(1080P),2560*1440(2K),3840*2160(4K)
Power Supply: DC 12V/2A
Dimension(WxDxH): 300X227X53mm
Working Temperature: -10°C~+55°C
Working Humidity: 10%~90%

Video Compression: H.264Video System NTSC/PAL
Operation System: Linux(embedded)
Analog video-input /output: 8 CH inputs / VGA and HDMI output
Composite Video Input: up to 12ch (Analog video + IP video)
Display resolution;
Analog: 5MP (20fps)
4MP/3MP(30fps)
1080P/720P/960H IP 4MP/3MP
1080P/ 720P
Record;
Analog:
5MP:12fps(each ch)
4MP:15fps(each ch)
3MP:20fps(each ch)
Maximum output Brandwidth: 96 Mbps
Maximum decode performance: 5MP: 96fps 4MP: 120fps 1080P: 240fps
Synchronous Playback: 8 CH
Network Type: Lan, DHCP, and DDNS
HDD interface: 2SATA HDDs, up to 12TB
PTZ Control: yes (RS485)
Mobile Surveillance: Support Mobile Phones based on iPhone and Android operation system
VGA/HDMI 1280*1024， 1440*900， 1280*720， 1920*1080 1680*1050 ，1600*1200， 1920*1200， 2560*1440 ，3840*2160

KGuard HD1681HD series 16 Channel Stand Alone Hybrid DVR
Support up to 24 cameras including BNCx16 and IPx8 (switch required)
Record in Megapixel HD resolution and various hybrid resolutions (960H, 720P/1080P) at the same time.
Support both Analog 1080P/720P/960H camera and ONVIF IP camera (8MP/5MP/4MP/3MP/2MP/1MP/D1).
Support mixing and installing Analog Cameras from different technologies (AHD 1080P/AHD 720P/Standard 960H).
No need to be done in groups of two.
Important image data can be saved to cloud ( Dropbox )
Connect max. 6ch/12ch/24ch of combined Onvif IP camera & analogue cameras to HD DVR
Easily connect DVR with mobile devices by scanning QR code via Kview pro. App.
Support up to 6TB HDD

Recording Bandwidth: Max 320Mbps
Recording Resolution: 8MP（4K), 5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9/10/13/14/16
live/Playback performance:
"4K: 4ch realtime
4MP: 8ch realtime
3MP: 10ch realtime
2MP: 16ch realtime"
Output Interface: 1 HDMI (up to 4K), 1 VGA
Display Resolution: 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440, 3840*2160
Alarm Input/out: 16ch in / 1ch out
Ethernet: RJ-45 port (1000M）
Smart Phone: iOS, Android
Internal: HDD 4 SATA HDDs,each HDD up to 6TB
e-Sata: yes
Line In: yes
USB: 1x3.0 USB for backup/upgrade , 2x 2.0 USB for mouse
AI-Registered quantity: 10000
AI-Maximum captured quantity: 200,000 faces
ONVIF: yes
POE: 16 PoE ports;single port up to 802.3at(30w)
Power consumption: (excluding hard disk) 12W
Power Supply: AC 110~240V ,PoE Swith :48V
Dimension: (W×D×H) 378*325.8*66mm

Recording Bandwidth: Max 320Mbps
Recording Resolution 8MP（4K),5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9/10/13/14/16/17/19/22/25/32/36
Live/Playback performance:
4K:4ch realtime
4MP:8ch realtime
2MP:16ch realtime
1MP:32ch realtime
Output Interface: 1 HDMI(up to 4K),1 VGA
Display Resolution: 1024*768,1280*720,1280*1024,1440*900,1920*1080,12560*1440,3840*2160
Alarm Input/out: 16ch in/4ch out
Ethernet: RJ-45 port (1000M）
Smart Phone: iOS, Android
Internal HDD: 8 SATA HDDs,each HDD up to 6TB
16 SATA HDDs,each HDD up to 6TB
(for models over 16ch,2HDD are recommended for simultaneous use)
e-Sata: yes
USB: 1x3.0 USB for backup/upgrade, 2x 2.0 USB for mouse
ONVIF: Yes
POE: NO
Power Supply: AC 100~240V
Power Consumption(NO HDD): 7W; 7.5W
Dimension: (W×D×H) 440*460*89mm440*460*164.5mm

Recording Bandwidth: Max 640Mbps
Recording Resolution: 8MP（4K),5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9/10/13/14/16/17/19/22/25/32/3642/49/56/64
Live/Playback performance
Output Interface: 1 HDMI(up to 4K),1 VGA
Display Resolution: 1024*768,1280*720,1280*1024,1440*900,1920*1080,12560*1440,3840*2160
Alarm Input/out: 16ch in/4ch out
Ethernet: RJ-45 port (1000M）
Smart Phone: iOS, Android
Internal HDD: 8 SATA HDDs,each HDD up to 6TB
16 SATA HDDs,each HDD up to 6TB
(for models over 16ch,2HDD are recommended for simultaneous use)
e-Sata: yes
USB: 1x3.0 USB for backup/upgrade, 2x 2.0 USB for mouse
ONVIF: Yes
POE: NO
Power Supply: AC 100~240V
Power Consumption(NO HDD): 8W; 8.5W
Dimension: (W×D×H) 440*460*89mm440*460*164.5mm

Recording Bandwidth: Max 128Mbps
Recording Resolution: 8MP(4K), 5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9
live/Playback performance:
"4K: 4ch realtime
4 MP/3MP/2MP: 8ch realtime"
Output Interface: 1 HDMI (up to 4K), 1 VGA
Display Resolution: 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440, 3840*2160
Alarm Input/out: 8ch in / 1ch out
Ethernet: RJ-45 port (1000M）
Smart Phone: iOS, Android
Internal HDD: 2 SATA HDDs, each HDD up to 8TB(16CH or more device min connect HDD has to be 2)
RS485: yes
e-Sata: yes
Line In: yes
USB: 1x3.0 USB for backup/upgrade , 2x 2.0 USB for mouse
AI-Registered quantity: 10000
AI-Maximum captured quantity: 200,000 faces
ONVIF: yes
Power consumption: (excluding hard disk) 5W
Power Supply: DC12V
Dimension: (W×D×H) 380*340*50mm

Recording Bandwidth: Max 320Mbps
Recording Resolution: 8MP（4K), 5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9/10/13/14/16
Live/Playback performance:
4K: 4ch realtime
4MP: 8ch realtime
3MP: 10ch realtime
2MP: 16ch realtime"
Output Interface: 1 HDMI (up to 4K), 1 VGA
Display Resolution: 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080,2560*1440, 3840*2160
Alarm Input/out: 16ch in / 1ch out
Ethernet: RJ-45 port (1000M）
Smart Phone: iOS, Android
Internal HDD: 4 SATA HDDs, each HDD up to 6TB(16CH or more device min connect HDD has to be 2)
RS485: yes
e-Sata: yes
Line In: yes
USB: 1x3.0 USB for backup/upgrade , 2x 2.0 USB for mouse
AI-Registered quantity: 10000
AI-Maximum captured quantity: 200,000 faces
ONVIF: yes
POE: NO
Power consumption (excluding hard disk): 6W
Power Supply: DC12V
Dimension: (W×D×H)" 378*325.8*66mm

Recording Bandwidth: Max 64Mbps（Max output 48M）
Recording Resolution 2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9
live/Playback performance;
Max 6ch total:2MP@100fps
Max 8ch total:720P@120fps
Output Interface: 1 HDMI, 1 VGA
Display Resolution: 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080
Alarm: Input/out no
Ethernet: RJ-45 port (100M）
Smart Phone: iOS, Android
Internal HDD: 1 SATA HDD, up to 6TB(max 8TB )
RS485: no
e-Sata: no
Line In: no
USB: 2x2.0 USB
ONVIF: yes
Power Supply: "DC12V/2A
Dimension: (W×D×H)" 300X227X53mm

Recording Bandwidth: Max 320Mbps
Recording Resolution: 8MP(4K), 5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P)
Display Split: 1/4/6/8/9/10/13/14/16
live/Playback performance:
4K - 4ch realtime
4MP - 8ch realtime
3MP - 10ch realtime
2MP - 16ch realtime"
Output Interface: 1 HDMI (up to 4K), 1 VGA
Display Resolution: 1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440, 3840*2160
Alarm Input/out: 16ch in / 1ch out
Ethernet: RJ-45 port (1000M）
Smart Phone: iOS, Android
Internal HDD: 2 SATA HDDs, each HDD up to 8TB(16CH need to add 2 HDD to use HDD group function)
RS485: yes
e-Sata: yes
Line In: yes
USB: 1x3.0 USB for backup/upgrade , 2x 2.0 USB for mouse
AI-Registered quantity: 10000
AI-Maximum captured quantity: 200,000 faces
ONVIF: yes
Power consumption (excluding hard disk): 6W
Power Supply: DC12V
Dimension: (W×D×H)" 380*340*50mm

Dəstə daxildir:
1 ədəd - Simsiz 1080p FHD
4ədəd - WiFi Live kamera
FHD (1920x1080) saniyədə 10 ~ 15 kadr qədər
Ethernet: RJ-45 portu
USB: 2x 2.0 USB
APP: iPhone, iPad, Android, Tablet
Daxili HDD: 1x SATA HDD
6TB HDD qədər dəstək
İş istiliyi -20 --- 50 ° C
İş rütubəti 90% RH
Enerji təchizatı 12V

Dəstə daxildir:
1ədəd - D2104HR-N-E-BK DVR
4ədəd - RS-CA256NCG-36W-PIR HD kamera
5.0MP 1/2.7" 2592 (H) x 1944 (V) pixel
Lens - 3.6mm/6mm optional
Sinxronizasiya - daxili
Video çıxış - 1 channel BNC
Gecə görüntü
Enerji təchizatı DC12V±10%
İş istiliyi -10°C~+55°C/
İş rütubəti 90% RH
Dəstə daxildir:
4 ədəd - CCTV cabel (18m)
1 ədəd - Adaptor 12v2 A

*D1104HR-N-A-GK+4
*RS-CA326NKB-36W-PIR

Dəstə daxildir:
1 ədəd - D1108HR-N-A Hybrid DVR-TVI
8 ədəd - 2.0MP HD AHD / CVI / TVI / CVBS bullet camera
CMOS Sensor; PAL: 25fps @ 1080P (1920x1080); 3.6 mm lens
Gecə görüntü
Suya davamlı: IP66
Temp. range -20 ° C - + 50 ° C
12VDC / 350mA.
Ölçülər: 145x66x65 mm

*D1104HR-N-A-GK+4
*RS-CA326NKB-36W-PIR

Dəstə daxildir:
1ədəd - D1104HR-N-A-FK Hybrid DVR
4ədəd - 2.0MP RS-CA226NCG-36W-PIR HD kamera (1920 (H) x1080 (V))
Lens 3.6mm/6mm optional
sinxronizasiya- daxili
Video çıxış - 1 port BNC
Gecə görüntü
Enerji təchizatı - DC12V±10%
İş istiliyi - 10°C~+55°C/
İş rütubəti - 95%RH

*D1104HR-N-A-GK+4
*RS-CA326NKB-36W-PIR

The H5SL camera is a versatile and cost-effective security solution that is backed by an Versatility meets high performance in the analytics-enabled Avigilon H6SL camera line. The camera line comes equipped with Next-Generation Video Analytics to proactively detect critical events and provide you with superior situational awareness of your site. Available as a bullet or dome form factor, these flexible cameras can fit into an extensive range of indoor and outdoor applications in education, commercial, government, retail and hospitality sectors for optimal protection of people and property.

See Your Site With Clarity
Monitor your site in high resolution with the H6SL camera line's faster imaging processors and cutting-edge sensors. For areas with high-contrast lighting, the cameras deliver sharp images with their robust Wide Dynamic Range. Adaptive IR options allow you to see clearly in low-light conditions.

Expedite Investigations With AI-Powered Analytics
Respond to critical events faster than ever before with Next-Generation Video Analytics for enhanced object detection and classification, along with Unusual Activity Detection (UAD) to flag atypical events.

Efficiently Manage Bandwidth
The H6SL camera line offers significantly improved bandwidth management, allowing you to achieve maximum image quality in all lighting conditions with less bandwidth requirements than ever before.

The Avigilon H6 Mini Dome brings an exceptional level of protection to indoor spaces with high-resolution images of up to 5 MP, a wide field of view and efficient bandwidth management in a compact design. This makes it an ideal solution for retail, commercial, hospitality and general indoor applications that require a small footprint, fixed lens camera without compromising on interior aesthetics.

Intelligent Motion, Powered By Next-Generation Video Analytics
Respond faster to potentially critical events with Unusual Activity Detection and classified object motion detection built into the camera. Save on video storage with the ability to configure the camera to only send motion events to Avigilon Control Center™ software if it is caused by a person, resulting in fewer unneeded recordings.

Wide Field Of View
Have superior situational awareness of your facility with two fixed lens options available: 2.9mm and 2.4mm.

Fast & Simple Installation
The camera's modular design allows it to snap into surface, in-ceiling or pendant adapters for quick and easy installations.

The Avigilon H5A IR Pan, Tilt and Zoom (PTZ) camera empowers security teams to see more in the dark with an automated IR illumination range of up to 300 meters1 and the ability to look up 20 degrees above the horizon. Leverage the camera's 360-degree views, up to 40x zoom2 and high-resolution imaging for superior situational awareness of vast sites in the most challenging lighting conditions. Whether it's a completely dark airfield or a poorly lit parking lot, the H5A IR PTZ is ready to take on the outdoors with its ability to resist water, corrosion, dust and impact.

Automated IR Illumination
The H5A IR PTZ can see up to 300 meters1 in complete darkness and can automatically adjust the IR projection angle according to its zoom level and field of view, ensuring the scene is consistently illuminated.

Above The Horizon Look Up
With the ability to look up 20 degrees above the horizon, the H5A IR PTZ provides more coverage than a typical PTZ camera.

Next-Generation Video Analytics With Auto-Tracking
The H5A IR PTZ comes equipped with Next-Generation Video Analytics and additional AI capabilities to proactively detect and automatically track people and vehicles, capturing greater detail of the subject for investigations.

The H5SL camera is a versatile and cost-effective security solution that is backed by an industry-leading warranty. With value and simplicity at the heart of this camera line, you will enjoy the ease of installation, flexible design features and various lens options the H5SL offers.

Multiple Lens Options
Choose from various lens types, including a new long-range lens that allows you to see with more clarity at farther distances.

The Avigilon H5A Fisheye Camera is a cost-effective and easy-to-install solution that provides 360° panoramic views of large areas from a single vantage point, bringing superior situational awareness without any blind spots. Facilities such as schools, retailers, offices, hospitals and manufacturing plants can leverage the camera's high-resolution video to monitor processes and optimize operational efficiencies, along with its analytics and AI capabilities to proactively detect critical events and enhance the productivity of security teams.

Panoramic Coverage With A Single Camera
Achieve superior situational awareness with fewer cameras and help lower overall video security deployment costs. Enrich investigations with optional audio recording for additional evidentiary detail.

The H5A camera line features our next-generation video analytics technology to help focus your attention on potentially critical events, providing a smarter and more powerful video security solution from the moment you set it up.

Advanced Object Detection
Offers more reliable detection of up to 50 objects in the scene, even if they are stationary, helping to alert you of important events that are happening within your facility.

Capacity: 500 GB
Interface: SATA
Form Factor: 3.5 Inch
Cache Size: 64 MB
Disk Speed: (RPM) 5400rpm
Dimensions (L X W X H): 5.79" x 4" x 1.03"

Capacity: 1 TB
Interface: SATA
Form Factor: 3.5 Inch
Cache Size: 64 MB
Disk Speed (RPM): 7200rpm
Dimensions (L X W X H): 5.79" x 4" x 1.03"

Drive Capacity: 4.0 TB
Cache Memory: 128 MB
Interface: SATA III (6 Gb/s)
Maximum Read: Speed 202 MB/s
Drive Type: HDD
Form Factor: 3.5"
Noise Level: 29.0 dB (Idle)
36.0 dB (Active)
Spindle Speed (RPM): 7200 RPM
Reliability / Data: Integrity
Load/Unload Cycles: 300,000
Non-Recoverable: Read Errors per Bits Read 14
Power Draw :9.1 W (Active)
5.8 W (Idle)
1.0 W (Standby)
Operating Shock: 30 G / 2.0 ms
Storage Shock: 300 G / 2.0 ms
Operating Temperature: 41 to 131°F / 5 to 55°C
Storage Temperature: -40 to 158°F / -40 to 70°C
Certifications: RoHS, as per Manufacturer
Dimensions (W x H x D): 1 x 5.8 x 4" / 26.1 x 147 x 101.6 mm
Weight: 1.6 lb / 0.7 kg
Package Weight: 1.55 lb
Box Dimensions (LxWxH): 6.75 x 6.45 x 1.5"

Interface: SATA 6.0Gb/s
Capacity: 500GB
RPM: 7200 RPM
Cache: 32MB
Average Latency: 4.17ms
Features
Toshiba's DT01ACA series of 7200 RPM 3.5-inch HDD deliver up to 3TB of storage capacity. Optimized for use in consumer and commercial desktop computers, All-in-One systems, gaming PCs, external storage and applications where capacity, performance and reliability are critical.
Usage: For Daily Computing
Dimensions
Form Factor: 3.5"
Height (maximum): 26.10mm
Width (maximum): 101.60mm
Length (maximum): 147.00mm

Storage Capacity: 1 TB
Platform Supported: PC
Drive Interface: SATA
Drive Interface: Standard SATA/600
Spindle Speed (rpm): 7200
Buffer: 32 MB
Drive Type: Internal
Form Factor: 3.5"
Height 1"
Width 4"
Depth 5.8"
Average Latency: 4.17 ms
Average Seek Time: 9.50 ms
SATA Pin: 7-pin

Size: φ146.7mm H:66.2mm

*Qiymətlə bağlı müraciət edin

Holder: 27cm
