Sophos APX 120 Indoor Access Point - 2x2 MIMO, dual radio, internal antennas. Includes mounting bracket for wall and/or 15/16"T-bar or flat ceiling.
5-Year warranty, no extended warranty available. Power adapter/PoE Injector not included but available for separate purchase. 11.8W max. power consumption (802.3af PoE injector required).
NOTE: Management in Sophos Central, Sophos Firewall (from v17.5.5), or Sophos UTM.

CS101-8FP: Cloud-managed, network access layer switch. 8 x GE PoE-capable ports (802.3af/802.3at) plus 2 x 1G SFP ports. Power-over-Ethernet support, total PoE budget 110W. Includes wall mount kit, power adapter and cable. Hardware purchase includes limited lifetime warranty replacement, local Web/CLI/SNMP management. Separate support subscription required for Sophos Central management, firmware updates, advance replacement RMA, 24x7 phone support.

Cloud-managed, network access layer switch. 24 x GE PoE-capable ports (802.3af/802.3at) plus 4 x 1G/10G SFP+ ports. Full Power-over-Ethernet support, total PoE budget 410W. Includes rackmount kit, power cable and console cable. Hardware purchase includes limited lifetime warranty replacement, local Web/CLI/SNMP management. Separate support subscription required for Sophos Central management, firmware updates, advance replacement RMA, 24x7 phone support.

Device Type: Radio access point
Form Factor: In-ceiling - indoor
Data Link Protocol: IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
Frequency Band: 2.4 GHz, 5 GHz
Performance Concurrent data rate (5 GHz): 1300 Mbps ¦ Concurrent data rate (2.4 GHz): 400 Mbps ¦ Peak data rate: 1.7 Gbps
Capacity: Wireless clients per Wi-Fi radio: 255 ¦ BSSIDs per radio: 16
Included Accessories: 2 x ceiling mounting clip
Dimensions (WxDxH): 16.5 cm x 16.5 cm x 3.8 cm
Weight: 460 g
Manufacturer Warranty: Limited lifetime warranty

Ports: One 10/100/1000BASE-T Ethernet network interface (RJ-45)
Connectivity, standard: IEEE 802.11 a/b/g/n/ac
Power Consumption: Direct DC source: 48Vdc nominal, +/- 5% Power over Ethernet (PoE): 48 Vdc (nominal) 802.3af/802.3at compliant source Maximum (worst-case) power consumption: 25.3W (802.3at PoE), 13.2W (802.3af PoE) or 25W (DC)
Wi-Fi antenna: Four integrated 2.4 GHz downtilt omni-directional antennas for 4x4 MIMO with maximum antenna gain of 4.3 dBi per antenna.
Radio coverage: 802.11ac – 5 GHz 4x4 MIMO (1,733 Mbps max rate) and 2.4 GHz 2x2 MIMO (800 Mbps max rate) radios, with a total of twelve integrated omni-directional downtilt antennas
Minimum dimensions ( H x W x D): 225 x 224 x 52 mm
Weight: 1150 g

Access Point Basic Flat Surface Mount Kit
Wall/Ceiling Mount for AP, see description for full compatibility list.

Product Type: Network device mounting kit
Placing / Mounting: Surface mountable
Dimensions (WxDxH): 17.8 cm x 16 cm x 5.1 cm
Weight: 181.4 g
Color: White

1 Gb/s 24 Ethernet port
Raf montajı
IEEE 802.1q (VLAN), IEEE 802.3ad (Bağlantı birləşdirmə İdarəetmə Protokolu), IEEE 802.1p (Prioritet etiketləri), IEEE 802.1d, Jumbo Çərçivə, MDI / MDIX Auto Detection
32 MB daxili yaddaş, 128 MB operativ yaddaş
Ölçüləri 440 x 44 x 173 mm, çəkisi 2.2 kq

24 1 Gbps Ethernet Limanları
2 uplink / yığma / SFP (1 Gb / s-ə qədər)
Raf montajı
IEEE 802.1q (VLAN), IEEE 802.3ad (Bağlantı birləşdirmə İdarəetmə Protokolu), IEEE 802.1p (Prioritet etiketləri), IEEE 802.1d, Jumbo Çərçivə, MDI / MDIX Auto Detection
16 MB daxili yaddaş, 128 MB operativ yaddaş
Ölçüləri 442 x 44 x 246 mm, çəkisi 2.72 kq

24 Port RJ-45 10/100/1000 Mbit / s otosensasiya edir
Yaddaş və prosessor Cortex-A9 @ 1 GHz, 128 MB flaş; paket bufer ölçüsü: 1.5 MB, 1 GB SDRAM
Gecikmə 100 Mb gecikmə <5 μs (LIFO 64 bayt paket) / 1000 Mb Gecikmə <5 μs (LIFO 64 baytlıq paket) / 10 Gb / Gecikmə <1,5 μs (64 bayt paket)
Ötürmə qabiliyyəti 95,2 Mpps qədər
Kommutasiya qabiliyyəti 128 Gb / s
Giriş gərginlikli 100-240 VAC
Güc istehlakı 34 W (maksimum)
Məhsul ölçüləri (H x W x D) 17.17 (w) x 6.3 (d) x 1.73 (h). (43.6 x 16 x 4.4 sm) (1U hündürlük)
Çəki 6.61 funt (3 kq)

I/O ports and slots
- 24 RJ-45 autosensing 10/100/1000 PoE+ ports; Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only
- 2 SFP 100/1000 Mbps ports (IEEE 802.3z Type 1000BASE-X, IEEE 802.3u Type 100BASE-FX)
Memory and processor
- ARM Cortex-A9 @ 400 MHz, 256 MB SDRAM, 64 MB flash; packet buffer: 1.5 MB
Mounting and enclosure
- Mounts in an EIA standard 19-inch telco rack or equipment cabinet (hardware included)
Performance
- 100 Mb Latency : < 7µs
- 1000 Mb Latency : < 2µs
- Throughput : Up to 77.3 Mpps (64-byte packets)
- Routing/Switching capacity : 52 Gbps
- Routing table size : 32 entries
- MAC address table size : 16000 entries
Reliability
- MTBF (years) : 57.1
Warranty
- HPE Limited Lifetime warranty

Product Differentiator (long): Advanced smart managed 48-port Gigabit PoE+ switch from our most popular switch series for small businesses. This model has 48x 10/100/1000 ports as well as 4 SFP ports. 24 of the ports support PoE+/PoE with a Power over Ethernet budget of 370 Watts.
Power Consumption Description: 481W (maximum), 54.8W (idle)
Input Voltage: 390.8W (maximum), 23.8W (idle)
External I/O Ports: (24) RJ-45 auto-negotiating 10/100/1000 PoE+ ports (24) RJ-45 auto-negotiating 10/100/1000 ports (4) SFP 100/1000 Mbps ports
Routing/switching: Capacity104 Gbps
Throughputup: to 77.3 Mpps
Management Features: Web browser SNMP IEEE 802.3 Ethernet mib
Weight (imperial): 9.7 lb
Weight (metric): 4.4 kg
Product Dimensions (imperial): 1.73 x 17.42 x 12.7 in
Product Dimensions (metric): 4.3 x 44.2 x 32.26 cm

Product Differentiator (long): Advanced smart web managed 24-port Gigabit PoE+ switch with 10G uplinks. This model has 24x 10/100/1000 PoE+/PoE enabled ports plus two 10GBASE T copper ports and two SFP+ ports for SFP+/SFP fiber connections. PoE power budget is 370 Watts.
Power Consumption Description: 425 W (maximum)
Input Voltage: 100 - 240 VAC, rated (depending on power supply chosen)
Latency:100 Mb Latency: < 5 µs 1000 Mb Latency: < 5 µs 10 Gbps Latency: < 1.5 µs
Routing/switching Capacity: 128 Gbps
Throughputup: to 95.2 Mpps
PoE Capability: 370 W PoE+
Management Features: IMC - Intelligent Management Center Limited command-line interface Web browser SNMP manager HTTPS RMON1 FTP Supported by HPE IMC and generic SNMP management platforms. Refer to documentation for MIB support details.
Detailed Product Description: HPE OfficeConnect 1950 switch with 24 1GbE, power-over-Ethernet-plus ports, 2 SFP+ ports, and 2 10GbE ports

Product Differentiator (long): Advanced smart web managed 48-port Gigabit PoE+ switch with 10G uplinks. This model has 48x 10/100/1000 PoE+/PoE enabled ports plus two 10GBASE T copper ports and two SFP+ ports for SFP+/SFP fiber connections. PoE power budget is 370 Watts.
Power Consumption Description: 470 W (maximum)
Input Voltage: 100 - 240 VAC, rated (depending on power supply chosen)
Latency: 100 Mb Latency: < 5 µs 1000 Mb Latency: < 5 µs 10 Gbps Latency: < 1.5 µs
Routing/switching Capacity: 176 Gbps
Throughputup to: 130.9 Mpps
PoE Capability: 370 W PoE+
Management Features: IMC - Intelligent Management Center Limited command-line interface Web browser SNMP manager HTTPS RMON1 FTP Supported by HPE IMC and generic SNMP management platforms. Refer to documentation for MIB support details.
Warranty Features: 1 year warranty
Detailed Product Description: HPE OfficeConnect 1950 switch with 48 1GbE, power-over-Ethernet-plus ports, 2 SFP+ ports, and 2 10GbE ports
Weight (imperial): 15.43 lb
Weight (metric): 7 kg
Product Dimensions (imperial): 17.32 x 16.54 x 1.73 in
Product Dimensions (metric): 44 x 42 x 4.4 cm

Form Factor: SFP+ Max
Data Rate: 10.3125Gbps
Wavelength: 850nm Max
Cable Distance: * 300m over OM3 MMF
Connector: LC duplex
Optical Components: VCSEL 850nm
Media: MMF
DOM Support :Yes
TX Power: -7.3~-1dBm
Receiver Sensitivity: < -11.1dBm
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Protocols: SFP+ MSA Compliant, CPRI, eCPRI

Form Type: SFP Max
Data Rate: 1000Mbps
Wavelength: 1310nm Max
Cable Distance: 10km over SMF
Interface: LC duplex
Optical Components: FP 1310nm
Cable Type: MMF*/SMF**
DOM Support: Yes
TX Power: -9.5 ~ -3dBm
Receiver Sensitivity: < -23dBm
Commercial Temperature Range: 0 to 70°C (32 to 158°F)
Protocols :SFF-8472 MSA Compliant, IEEE 802.3ah-2004

Wi-Fi isti nöqtəsi
Wi-Fi standartı: 802.11n
Maks. sürət: 300 Mbit / s
Port sürəti 100 Mbit / s

Wi-Fi-ADSL2 + router
Wi-Fi standartı: 802.11n
Maks. sürət: 150 Mbit / s
VPN dəstəyi
Port sürəti 100 Mbit / s

Wi-Fi-ADSL2 + router
Wi-Fi standartı: 802.11n
Maks. sürət: 300 Mbit / s
4xLAN keçid
VPN dəstəyi
Port sürəti 100 Mbit / s

802.3u 10 / 100Base-TX, 100Base-FX standartlarına uyğundur
Yarım Dupleks / Tam Dupleks ötürmə rejiminin avtomatik danışıqları
20 km məsafəyə qədər məsafəsini uzadır

802.3u 10 / 100Base-TX, 100Base-FX dəstəkləyir
Yarım dupleks / tam dupleks üzərində avtomatik danışıqlar
Eyni fiber optik kabeldə məlumat ötürən və qəbul edən WDM texnologiyasını dəstəkləyir
20 km məsafəyə qədər optik bağlantı dəstəyi

16 10/100 Mbit / s avtomatik danışıq portları, RJ45 konnektoru ilə, avtomatik MDI / MDIX dəstəyi
Etibarlı məlumat ötürülməsi üçün IEEE 802.3x axını idarəetmə
Masaüstü və ya divara montaj üçün plastik bir mənzil
Plug and Play texnologiyasını dəstəkləyin, əlavə konfiqurasiya tələb olunmur

5 10/100 Mbit / s avtomatik danışıq portları, RJ45 konnektoru ilə, avtomatik MDI / MDIX dəstəyi
Green Ethernet texnologiyası enerji istehlakının 60% -ə qədər qənaət edir
Etibarlı məlumat ötürülməsi üçün IEEE 802.3x axını idarəetmə
Masaüstü yerləşdirmə üçün plastik mənzil
Plug and Play texnologiyasını dəstəkləyin, əlavə konfiqurasiya tələb olunmur

8 10/100 Mbit / s avtomatik danışıq portları, RJ45 konnektoru ilə, avtomatik MDI / MDIX dəstəyi
Green Ethernet texnologiyası elektrik istehlakının 73% -ə qədər qənaət edir
Etibarlı məlumat ötürülməsi üçün IEEE 802.3x axını idarəetmə
Masaüstü yerləşdirmə üçün plastik mənzil
Plug and Play texnologiyasını dəstəkləyin, əlavə konfiqurasiya tələb olunmur
